DC DC 컨버터
| 사진 | 제조사 부품 번호 | 재고 상태 | 가격 | 수량 | 데이터시트 | 시리즈 | 패키지/케이스 | 패키징 | 제품 상태 | 유형 | 출력 수 | 전압 - 입력(최소) | 전압 - 입력(최대) | 전압 - 출력 1 | 전압 - 출력 2 | 전압 - 출력 3 | 전압 - 출력 4 | 전류 - 출력(최대) | 전력(와트) | 전압 - 절연 | 응용 프로그램 | 기능 | 작동 온도 | 효율성 | 등급 | 자격 | 장착 유형 | 크기/치수 | 공급자 장치 패키지 | 제어 기능 | 승인 기관 | 표준 번호 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HRL3024S1K0PDC DC CONVERTER 1000V 30W |
10 | - |
|
데이터시트 |
HRL30 (30W) | 14-DIP Module | Tray | Active | High Voltage - Non-Isolated Module | 1 | 22V | 30V | 1000V | - | - | - | 30mA | 30 W | - | ITE (Commercial) | Adjustable Output, Baseplate | -40°C ~ 70°C | 85% | - | - | Through Hole | 3.00" L x 2.00" W x 0.73" H (76.2mm x 50.8mm x 18.6mm) | - | - | CE, UKCA, UL | 62368-1 |
|
DCM3623T50M53C2M00DC DC CONVERTER 48V 320.2W |
21 | - |
|
데이터시트 |
VI Chip® DCM® (320W) | 9-DIP Module | Bulk | Active | Isolated Module | 1 | 16V | 50V | 48V | - | - | - | 6.67A | 320.2 W | 2.25 kV | ITE (Commercial) | OCP, OTP, OVP, SCP, UVLO | -55°C ~ 125°C | 92.6% | - | - | Through Hole | 1.52" L x 0.90" W x 0.29" H (38.7mm x 22.8mm x 7.3mm) | - | - | - | - |
|
DCM4623TD2H53E0M00DC DC CONVERTER 48V 504W |
21 | - |
|
데이터시트 |
VI Chip® DCM® (500W) | 9-DIP Module | Bulk | Active | Isolated Module | 1 | 200V | 420V | 48V | - | - | - | 10.5A | 504 W | 4.242 kV | ITE (Commercial) | OCP, OTP, OVP, SCP, UVLO | -55°C ~ 125°C | 93.3% | - | - | Through Hole | 1.89" L x 0.90" W x 0.29" H (47.9mm x 22.8mm x 7.3mm) | - | - | - | - |
|
SMHV05100DC DC CONVERTER 10000V 1W |
12 | - |
|
데이터시트 |
SMHV | 9-DIP Module | Bulk | Active | High Voltage - Non-Isolated Module | 1 | 4.5V | 5.5V | 10000V | - | - | - | 100µA | 1 W | - | ITE (Commercial) | - | -55°C ~ 70°C | 60% | - | - | Through Hole | 0.85" L x 0.85" W x 0.60" H (21.6mm x 21.6mm x 15.2mm) | - | - | - | - |
|
|
DCM4623TD2K17E0M00DC DC CONVERTER 15V 500W |
25 | - |
|
데이터시트 |
VI Chip® DCM® (500W) | 9-DIP Module | Tray | Active | Isolated Module | 1 | 160V | 420V | 15V | - | - | - | 33.4A | 500 W | 4.242 kV | ITE (Commercial) | OCP, OTP, OVP, SCP, UVLO | -55°C ~ 125°C | 93.4% | - | - | Through Hole | 1.89" L x 0.90" W x 0.29" H (47.9mm x 22.8mm x 7.3mm) | 4623 | - | - | - |
|
15A12-P4A-SERIES DC TO HVDC CONVERTER, S |
8 | - |
|
데이터시트 |
UltraVolt® 15A | Module | Bulk | Active | High Voltage - Non-Isolated Module | 2 | 11V | 16V | 15000V | - | - | - | 260µA | 4 W | - | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 65°C | - | - | - | Through Hole | 4.70" L x 1.52" W x 1.00" H (119.4mm x 38.7mm x 25.4mm) | - | Enable, Active High | CE, cUL, cURus, UL | 60950-1 |
|
DCM3714BD2K13E0T09DC DC CONVERTER 12V 500W |
3 | - |
|
데이터시트 |
VI Chip® DCM® (500W) | 9-DIP Module | Box | Active | Isolated Module | 1 | 160V | 420V | 12V | - | - | - | 41.67A | 500 W | 2.121 kV | ITE (Commercial) | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | -40°C ~ 125°C | 92% | - | - | Through Hole | 3.83" L x 1.40" W x 0.37" H (97.3mm x 35.5mm x 9.3mm) | - | - | - | - |
|
|
2D24-N1D-SERIES DC TO HVDC CONVERTER, S |
5 | - |
|
데이터시트 |
UltraVolt® D | 8-DIP Module | Bulk | Active | High Voltage - Non-Isolated Module | 1 | 22V | 26V | 0 ~ 2000V | - | - | - | 500µA | 1 W | - | ITE (Commercial) | Adjustable Output, Remote On/Off | -10°C ~ 65°C | - | - | - | Through Hole | 2.50" L x 1.73" W x 0.69" H (63.5mm x 44.0mm x 17.5mm) | - | - | - | - |
|
|
DCM3714BD2K31E0T09DC DC CONVERTER 28V 500W |
2 | - |
|
데이터시트 |
VI Chip® DCM® (500W) | 9-DIP Module | Box | Active | Isolated Module | 1 | 160V | 420V | 28V | - | - | - | 17.86A | 500 W | 2.121 kV | ITE (Commercial) | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | -40°C ~ 125°C | 93.6% | - | - | Through Hole | 3.83" L x 1.40" W x 0.37" H (97.3mm x 35.5mm x 9.3mm) | - | - | - | - |
|
|
DCM3714BD2H26F0T09DC DC CONVERTER 24V 600W |
9 | - |
|
데이터시트 |
VI Chip® DCM® (600W) | 9-DIP Module | Box | Active | Isolated Module | 1 | 200V | 420V | 24V | - | - | - | 25A | 600 W | 2.121 kV | ITE (Commercial) | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | -40°C ~ 125°C | 93% | - | - | Through Hole | 3.83" L x 1.40" W x 0.37" H (97.3mm x 35.5mm x 9.3mm) | - | - | - | - |
|
|
DCM3714BD2H53E0T09DC DC CONVERTER 48V 500W |
2 | - |
|
데이터시트 |
VI Chip® DCM® (500W) | 9-DIP Module | Box | Active | Isolated Module | 1 | 200V | 420V | 48V | - | - | - | 10.42A | 500 W | 2.121 kV | ITE (Commercial) | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | -40°C ~ 125°C | 93.4% | - | - | Through Hole | 3.74" L x 1.40" W x 0.37" H (95.1mm x 35.5mm x 9.3mm) | - | - | - | - |
|
10A12-P4DC DC CONVERTER 10000V 4W |
15 | - |
|
데이터시트 |
UltraVolt® 10A | Module | Bulk | Active | High Voltage - Non-Isolated Module | 1 | 11V | 16V | 10000V | - | - | - | 400µA | 4 W | - | ITE (Commercial) | - | -40°C ~ 65°C | - | - | - | Through Hole | 3.72" L x 1.52" W x 1.00" H (94.6mm x 38.7mm x 25.4mm) | - | Enable, Active High | CE, cURus | - |
|
VI-25H-IU-B1DC DC CONVERTER 52V 200W |
3 | - |
|
데이터시트 |
VI-200™ (200W) | Full Brick | Bulk | Active | Isolated Module | 1 | 100V | 200V | 52V | - | - | - | 3.85A | 200 W | 3 kV | ITE (Commercial) | OCP, OTP, OVP, SCP | -40°C ~ 85°C | 90% | - | - | Through Hole | 4.60" L x 2.40" W x 1.07" H (116.8mm x 61.0mm x 27.1mm) | - | - | - | - |
|
|
15A24-P15A-SERIES DC TO HVDC CONVERTER, S |
2 | - |
|
데이터시트 |
A | Module | Bulk | Active | High Voltage - Non-Isolated Module | 1 | 23V | 30V | 0 ~ 15000V | - | - | - | 1mA | 15 W | - | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 65°C | - | - | - | Through Hole | 4.70" L x 1.52" W x 1.00" H (119.4mm x 38.7mm x 25.4mm) | - | Enable, Active High | CE, cURus | 60950-1 |
|
V375A28H600BGDC DC CONVERTER 28V 600W |
5 | - |
|
데이터시트 |
Maxi (600W) | Full Brick | Bulk | Active | Isolated Module | 1 | 250V | 425V | 28V | - | - | - | 21.43A | 600 W | 3 kV | ITE (Commercial) | OVP, UVLO | -40°C ~ 100°C | 87.8% | - | - | Through Hole | 4.60" L x 2.20" W x 0.62" H (116.8mm x 55.9mm x 15.7mm) | - | - | - | - |
|
1/4AA24-P20-MDC DC CONVERTER 250V 15W |
11 | - |
|
데이터시트 |
UltraVolt® AA | 11-DIP Module | Bulk | Active | High Voltage - Non-Isolated Module | 1 | 23V | 30V | 250V | - | - | - | 80mA | 15 W | - | ITE (Commercial) | - | -40°C ~ 65°C | - | - | - | Through Hole | 3.00" L x 1.53" W x 0.84" H (76.2mm x 38.9mm x 21.4mm) | - | Enable, Active High | CE, cURus | - |
|
10A24-P30-I5DC DC CONVERTER 10000V 30W |
12 | - |
|
데이터시트 |
UltraVolt® 10A | Module | Box | Active | High Voltage - Non-Isolated Module | 1 | 23V | 30V | 10000V | - | - | - | 3mA | 30 W | - | ITE (Commercial) | - | -40°C ~ 65°C | - | - | - | Through Hole | 3.72" L x 1.52" W x 1.00" H (94.6mm x 38.7mm x 25.4mm) | - | Enable, Active High | CE, cURus | - |
|
|
40A24-P30-EA-SERIES DC TO HVDC CONVERTER, S |
6 | - |
|
데이터시트 |
Ultravolt® 40A | Module | Bulk | Last Time Buy | High Voltage - Non-Isolated Module | 1 | 23V | 30V | 40000V | - | - | - | 750µA | 30 W | - | ITE (Commercial) | - | -40°C ~ 65°C | - | - | - | Through Hole | 7.96" L x 1.60" W x 1.41" H (202.2mm x 40.6mm x 35.7mm) | - | Enable, Active High | CE, cURus | 60950-1 |
|
30A24-P30A-SERIES DC TO HVDC CONVERTER, S |
3 | - |
|
데이터시트 |
Ultravolt® 30A | Module | Bulk | Last Time Buy | High Voltage - Non-Isolated Module | 1 | 23V | 30V | 30000V | - | - | - | 1mA | 30 W | - | ITE (Commercial) | - | -40°C ~ 65°C | - | - | - | Through Hole | 6.96" L x 1.60" W x 1.14" H (176.8mm x 40.6mm x 40.6mm) | - | Enable, Active High | CE, cURus | 60950-1 |
|
|
2C24-P125DC/DC CONVERTER |
12 | - |
|
데이터시트 |
C | Module | Bulk | Active | High Voltage - Non-Isolated Module | 1 | 23V | 30V | 0 ~ 2000V | - | - | - | 62mA | 124 W | - | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 65°C | - | - | - | Through Hole | 4.50" L x 4.00" W x 1.06" H (114.3mm x 101.6mm x 27.0mm) | - | Enable, Active High | CE, cUL, cURus, UL | 60950-1 |
