DC DC 컨버터
| 사진 | 제조사 부품 번호 | 재고 상태 | 가격 | 수량 | 데이터시트 | 시리즈 | 패키지/케이스 | 패키징 | 제품 상태 | 유형 | 출력 수 | 전압 - 입력(최소) | 전압 - 입력(최대) | 전압 - 출력 1 | 전압 - 출력 2 | 전압 - 출력 3 | 전압 - 출력 4 | 전류 - 출력(최대) | 전력(와트) | 전압 - 절연 | 응용 프로그램 | 기능 | 작동 온도 | 효율성 | 등급 | 자격 | 장착 유형 | 크기/치수 | 공급자 장치 패키지 | 제어 기능 | 승인 기관 | 표준 번호 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
KDHM-B-12S600N-RDC DC CONVERTER |
100 | - |
|
데이터시트 |
KDHM-B | 6-DIP Module, 5 Leads | Tray | Active | High Voltage - Non-Isolated Module | 1 | 11V | 16V | 0 ~ -600V | - | - | - | 1mA | 600 mW | - | ITE (Commercial) | Adjustable Output | -20°C ~ 65°C | - | - | - | Through Hole | 1.00" L x 0.60" W x 0.41" H (25.4mm x 15.2mm x 10.5mm) | - | - | - | - |
|
|
KDHM-B-5S600N-VDC DC CONVERTER |
100 | - |
|
데이터시트 |
KDHM-B | 6-DIP Module, 5 Leads | Bulk | Active | High Voltage - Non-Isolated Module | 1 | 4.5V | 7V | 0 ~ -600V | - | - | - | 1mA | 600 mW | - | ITE (Commercial) | Adjustable Output | -20°C ~ 65°C | - | - | - | Through Hole | 1.00" L x 0.60" W x 0.41" H (25.4mm x 15.2mm x 10.5mm) | - | - | - | - |
|
|
KDHM-B-24S600P-RDC DC CONVERTER |
100 | - |
|
데이터시트 |
KDHM-B | 6-DIP Module, 5 Leads | Tape & Box (TB) | Active | High Voltage - Non-Isolated Module | 1 | 21V | 28V | 0 ~ 600V | - | - | - | 1mA | 600 mW | - | ITE (Commercial) | Adjustable Output | -20°C ~ 65°C | - | - | - | Through Hole | 1.00" L x 0.60" W x 0.41" H (25.4mm x 15.2mm x 10.5mm) | - | - | - | - |
|
|
KDHM-B-12S600P-VDC DC CONVERTER |
100 | - |
|
데이터시트 |
KDHM-B | 6-DIP Module, 5 Leads | Retail Package | Active | High Voltage - Non-Isolated Module | 1 | 11V | 16V | 0 ~ 600V | - | - | - | 1mA | 600 mW | - | ITE (Commercial) | Adjustable Output | -20°C ~ 65°C | - | - | - | Through Hole | 1.00" L x 0.60" W x 0.41" H (25.4mm x 15.2mm x 10.5mm) | - | - | - | - |
|
|
KDHM-B-5S600P-RDC DC CONVERTER |
100 | - |
|
데이터시트 |
KDHM-B | 6-DIP Module, 5 Leads | Retail Package | Active | High Voltage - Non-Isolated Module | 1 | 4.5V | 7V | 0 ~ 600V | - | - | - | 1mA | 600 mW | - | ITE (Commercial) | Adjustable Output | -20°C ~ 65°C | - | - | - | Through Hole | 1.00" L x 0.60" W x 0.41" H (25.4mm x 15.2mm x 10.5mm) | - | - | - | - |
|
|
KDHM-B-24S600P-VDC DC CONVERTER |
100 | - |
|
데이터시트 |
KDHM-B | 6-DIP Module, 5 Leads | Tape & Box (TB) | Active | High Voltage - Non-Isolated Module | 1 | 21V | 28V | 0 ~ 600V | - | - | - | 1mA | 600 mW | - | ITE (Commercial) | Adjustable Output | -20°C ~ 65°C | - | - | - | Through Hole | 1.00" L x 0.60" W x 0.41" H (25.4mm x 15.2mm x 10.5mm) | - | - | - | - |
|
|
KDHM-B-12S600P-RDC DC CONVERTER |
100 | - |
|
데이터시트 |
KDHM-B | 6-DIP Module, 5 Leads | Retail Package | Active | High Voltage - Non-Isolated Module | 1 | 11V | 16V | 0 ~ 600V | - | - | - | 1mA | 600 mW | - | ITE (Commercial) | Adjustable Output | -20°C ~ 65°C | - | - | - | Through Hole | 1.00" L x 0.60" W x 0.41" H (25.4mm x 15.2mm x 10.5mm) | - | - | - | - |
|
|
KDHM-B-24S600N-VDC DC CONVERTER |
100 | - |
|
데이터시트 |
KDHM-B | 6-DIP Module, 5 Leads | Tray | Active | High Voltage - Non-Isolated Module | 1 | 21V | 28V | 0 ~ -600V | - | - | - | 1mA | 600 mW | - | ITE (Commercial) | Adjustable Output | -20°C ~ 65°C | - | - | - | Through Hole | 1.00" L x 0.60" W x 0.41" H (25.4mm x 15.2mm x 10.5mm) | - | - | - | - |
|
|
URD24S12-200WDC DC CONVERTER 200W |
20,000 | - |
|
- |
* | Module | Case | Active | Isolated Module | 1 | 18V | 72V | 12V | - | - | - | 16.7A | 200 W | - | ITE (Commercial) | - | -40°C ~ 85°C | 80 ~ 88% | - | - | Through Hole | - | - | - | CE | - |
|
|
URD12S05-200WDC DC CONVERTER 200W |
20,000 | - |
|
- |
* | Module | Case | Active | Isolated Module | 1 | 9V | 36V | 5V | - | - | - | 40A | 200 W | - | ITE (Commercial) | - | -40°C ~ 85°C | 80 ~ 88% | - | - | Through Hole | - | - | - | CE | - |
|
|
URD12S24-200WDC DC CONVERTER 200W |
20,000 | - |
|
- |
* | Module | Case | Active | Isolated Module | 1 | 9V | 36V | 24V | - | - | - | 8.33A | 200 W | - | ITE (Commercial) | - | -40°C ~ 85°C | 80 ~ 88% | - | - | Through Hole | - | - | - | CE | - |
|
|
URD24S05-200WDC DC CONVERTER 200W |
20,000 | - |
|
- |
* | Module | Case | Active | Isolated Module | 1 | 18V | 72V | 5V | - | - | - | 40A | 200 W | - | ITE (Commercial) | - | -40°C ~ 85°C | 80 ~ 88% | - | - | Through Hole | - | - | - | CE | - |
|
|
URD24S24-200WDC DC CONVERTER 200W |
20,000 | - |
|
- |
* | Module | Case | Active | Isolated Module | 1 | 18V | 72V | 24V | - | - | - | 8.33A | 200 W | - | ITE (Commercial) | - | -40°C ~ 85°C | 80 ~ 88% | - | - | Through Hole | - | - | - | CE | - |
|
|
URD12S12-200WDC DC CONVERTER 200W |
20,000 | - |
|
- |
* | Module | Case | Active | Isolated Module | 1 | 9V | 36V | 12V | - | - | - | 16.7A | 200 W | - | ITE (Commercial) | - | -40°C ~ 85°C | 80 ~ 88% | - | - | Through Hole | - | - | - | CE | - |
|
|
ATMV24VPN250V8MA24W Isolated DC-DC Power Module |
100 | - |
|
데이터시트 |
- | 5-DIP Module | Tape & Box (TB) | Active | Isolated Module | 2 | 18V | 36V | 250V | -250V | - | - | 8mA, 8mA | 4 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 73% | - | - | Through Hole | 2.00" L x 1.00" W x 0.41" H (50.8mm x 25.4mm x 10.5mm) | - | - | - | - |
|
|
ATMV12VPN250V8MA24W Isolated DC-DC Power Module |
100 | - |
|
데이터시트 |
- | 5-DIP Module | Tape & Box (TB) | Active | Isolated Module | 2 | 10V | 18V | 250V | -250V | - | - | 8mA, 8mA | 4 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 72% | - | - | Through Hole | 2.00" L x 1.00" W x 0.41" H (50.8mm x 25.4mm x 10.5mm) | - | - | - | - |
|
HPS4540N010N26RDC DC CONVERTER -54V 540W |
50 | - |
|
데이터시트 |
HPS | Half Brick | Tray | Active | Isolated Module | 1 | 36V | 75V | -54V | - | - | - | 10A | 540 W | 2.25 kV | ITE (Commercial) | Adjustable Output, Baseplate, Remote On/Off | -40°C ~ 85°C (With Derating) | 93% | - | - | Through Hole | 2.41" L x 2.29" W x 0.51" H (61.2mm x 58.2mm x 12.9mm) | Half Brick | Enable, Active Low | CE | 62368-1 |
|
|
KDHM-B-12S1000N-RDC DC CONVERTER |
100 | - |
|
데이터시트 |
KDHM-B | 6-DIP Module, 5 Leads | Retail Package | Active | High Voltage - Non-Isolated Module | 1 | 11V | 16V | 0 ~ -1000V | - | - | - | 500µA | 500 mW | - | ITE (Commercial) | Adjustable Output | -20°C ~ 65°C | - | - | - | Through Hole | 1.00" L x 0.60" W x 0.41" H (25.4mm x 15.2mm x 10.5mm) | - | - | - | - |
|
|
KDHM-B-24S1000N-VDC DC CONVERTER |
100 | - |
|
데이터시트 |
KDHM-B | 5-DIP Module | Tray | Active | High Voltage - Non-Isolated Module | 1 | 21V | 28V | 0 ~ -1000V | - | - | - | 500µA | 500 mW | - | ITE (Commercial) | Adjustable Output | -20°C ~ 65°C | - | - | - | Through Hole | 1.00" L x 0.60" W x 0.41" H (25.4mm x 15.2mm x 10.5mm) | - | - | - | - |
|
|
KDHM-B-5S1000P-RDC DC CONVERTER |
100 | - |
|
데이터시트 |
KDHM-B | 6-DIP Module, 5 Leads | Tape & Box (TB) | Active | High Voltage - Non-Isolated Module | 1 | 4.5V | 7V | 0 ~ 1000V | - | - | - | 500µA | 500 mW | - | ITE (Commercial) | Adjustable Output | -20°C ~ 65°C | - | - | - | Through Hole | 1.00" L x 0.60" W x 0.41" H (25.4mm x 15.2mm x 10.5mm) | - | - | - | - |
